12V135 Series Diesel Engine for Generating Sets

12V135 Series Diesel Engine for Generating Sets

Power Range: 398ps~755ps

Main Specifications of 12V135 Series Diesel Engine
Model 12V135AZD 12V135AZLD/AZLD-1 12V135BZLD/BZLD-3 12V135BZLD2 12V135BZLD1
Engine Type V Sharp, Direct Injection, 4-Stroke, Water Cooled
Aspiration Type Turbocharged Turbocharged with Intercooler
1h Power (kW) 330 373 445.5 505 555
Bore/Stroke (mm) 135/150 135/155
Compression Ratio 16:01 16.4:1 16:01
Total Displacement (L) 25.8 26.6
Specific Fuel Consumption at Rated Condition (g/kW.h) 210 200
Lubricating Oil Consumption (g/kW.h) 1 0.7
Stable State Rate (%) 5 5(0~5% Adjustable)
Type of Governor Mechanical Governor/ Electronic Governor (Optional) Electronic Governor
Idle Speed (rpm) 500 750
Rated Speed (rpm) 1500 1500/1800 1500
Noise (dB) ≤117 ≤119
FSN (Filter Smoke Number) ≤3 ≤2.5 ≤2.0 ≤2.5
Net Weight (kg) 1850 1900 1950
