SD-SC Open Type Diesel Generator (69 - 900KVA)

SD-SC Open Type Diesel Generator
(69 - 900KVA)

H SERIES DIESEL GENERATOR SETS
These generator sets are powered by H series diesel engines designed and produced by Shanghai New Power Automotive Technology Company Limited. The generator sets are produced in 6 different models with a rated power range of 50-150 kW. Each genset is equipped with an automatic starting device and an optional ATS switch cabinet. These components allow for automated starting and switchover between generator sets. The sets all feature high voltage regulation accuracy, dynamic performance, minimal voltage wave distortion, high efficiency, and reliability. Thanks to their maintenance-free battery ignition system, the generator sets can be started simply by filling the fuel and coolant tanks and flipping the power switch. These sets are incredibly user freindly and easy to maintain.

The Main Technical Parameters
No Model Standby power(KVA) Prime Power(KVA) Dimension(mm) Engine Type
1 SD-SC63 69 63 1940*940*1358 SC4H95D2
2 SD-SC80 88 80 1980*940*1358 SC4H115D2
3 SD-SC100 110 100 1985*1000*1470 SC4H160D2
4 SD-SC125 138 125 1985*1000*1470 SC4H180D2
6 SD-SC160 176 160 2400*1050*1535 SC7H230D2
7 SD-SC188 207 188 2400*1050*1535 SC7H250D2
8 SD-SC200 220 200 2540*1120*1620 SC9D280D2
9 SD-SC250 275 250 2700*1120*1655 SC9D340D2
11 SD-SC313 344 313 3220*1380*1755 SC13G420D2
13 SD-SC350 385 350 3220*1380*1755 SC12E460D2
14 SD-SC375 413 375 3200*1385*1850 SC12E500D2
16 SD-SC450 495 450 3550*1600*2205 SC25G610D2
17 SD-SC500 550 500 3570*1600*2205 SC25G690D2
18 SD-SC563 619 563 3570*1600*2205 SC27G755D2
19 SD-SC625 688 625 3570*1750*2205 SC27G830D2
20 SD-SC682 750 682 3570*1750*2205 SC27G900D2
21 SD-SC750 825 750 3800*1410*1880 SC33W990D2
22 SD-SC900 990 900 3800*1410*1880 SC33W1150D2

* The above parameters are for reference only and subject to change without prior notice.

D SERIES DIESEL GENERATOR SETS
The D series diesel generator sets are powered by high quality Shanghai New Power Automotive Technology Company Limited. engines. D series generator sets are manufactured in 3 different models with rated power output ranges from 160-200 kW. Each genset is equipped with an automatic starting device and an optional ATS switch cabinet. These components allow for automated starting and switchover between generator sets. Efficiency is the target of all power generation equipment and our D series generators provide oustanding efficiency along with dynamic performance and reliability for backup power or primary power generation.

G SERIES DIESEL GENERATOR SETS
Shanghai New Power Automotive Technology Company Limited. produces the G series diesel generator sets for large power generation operations. Each piece of electrical equipment is outfitted with an automatic ignition device and can be equipped with an optional ATS switch cabinet. These components allow for automated ignition and switchover of generator sets. The voltage regulation accuracy, dynamic performance, minimal wave distortion, and reliability of this equipment is the reason for its popularity in international markets. Thanks to their maintenance-free battery ignition system, the generator sets can be started simply by filling the fuel and coolant tanks and flipping the power switch.

W SERIES DIESEL GENERATOR SETS
The W series diesel generator sets were designed and put into production by Shanghai New Power Automotive Technology Company Limited. in order to provide high efficiency power for large scale generation operations. The W series generators feature rated power of an impressive 600kW with an engine power of 660kW. These heavy-duty generators feature automatic ignition systems and can be equipped with an ATS switch cabinet for automatic switching of generator sets. Each piece of equipment is highly reliable and features a maintenance-free battery ignition system for starting the machine with ease.

E SERIES DIESEL GENERATOR SETS
The E series diesel generator sets are engineered by Shanghai New Power Automotive Technology Company Limited. for high reliability power generation as backup or primary power systems. Each genset is equipped with an automatic starting device and an optional ATS switch cabinet. These components allow for automated starting and switchover between generator sets. With a rated standby power of 300kW, these generators are suitable for any number of application possibilities. The sets all feature high voltage regulation accuracy, dynamic performance, minimal voltage wave distortion, high efficiency, and reliability.

The Main Electrical Performance Indicators
（Voltage） （Frequency）
Steady-state deviation /% Transient deviation /% Modulation/% Recovery time /s Frequency drop /s Steady-state frequency band /% Transient deviation Recovery time /s
≤±2.5 -20～+25 0.3 ≤6 ≤5 ≤1.5 -10～+12 ≤5
Voltage range: no-load voltage regulation range is 95% - 105% of rated voltage.

Note: 1. Unless otherwise required, the above generator sets are auto-starting type with voltage of 400 V and frequency of 50 Hz. 2. The above generator sets can be designed to feature automatic parallel operation as well as auto-starting and auto-switchover.
