R Series Diesel Engine

R Series Diesel Engine

SDEC's SC 25E/28R series engine is a newly introduced and developed small-displacement diesel engine after SDEC joined SAIC, and it can fully meet the National IV and the National V Emission Standard. This engine is introduced from the Italian VM Company, embodying advanced technology and sophisticated craft, and it is mounted in many of the worldwide best-selling vehicle models including Alfa Romeo, Chrysler Voyager, Land Rover Defender, JEEP Cherokee, and LDV. During the process of introduction and production, SDEC inherited its sophisticated manufacturing process and outstanding performance, ensuring the product quality. With the development of the domestic auto market, this engine will be a preferred power for many domestic diesel vehicles.

Technologies Functions Advantages
16 Valve Cylinder Increase the inlet flow Improved the engine performance
(horsepower and torque)
The second generation BOSCH high pressure share-rail fuel system,CP1H oil pump Each cycle can spray five times,
maximum fuel injection pressure can reach 1600bar,
and the flow deviation
of the fuel injector can be controlled.		 Lower emission, noise and fuel consumption for the engine
Electronic control and variable cross-section supercharger VGT/FGT, optional Wider engine torque, faster engine dynamic response Improved the driving performance of
the finished vehicle,
lower emission and fuel consumption
Tappet roller pin Reduce the height and friction losses for the engine Smaller dimensions for the engine and reduced the fuel consumption
Hydraulic gap adjuster Automatic adjustment for the valve clearance No need to adjust the maintenance
work for the valve gear
Share-rail pressure control valves Better control for the share-rail pressure Improved the driving performance
of the finished vehicle,
the stability of the cold
start and the engine operation
DOHC(Double Overhead Camshaft) Increase the cooling fluid and air flow rate and improve the engine performance With improved engine
power
Technical Specifications
Power Range: 90~165PS (Applies to Light-Duty Vehicles, SUVs)
Model Unit EuroIV
SC25R SC28R
Type
Water cooling, In-line, Electrical, 4-Valve
Aspiration mm×mm VGT (FGT Optional)
Bore×Stroke L 92×94 94×100
Total Displacement
2.5 2.8
Rated Power/Rated Speed kW/r/min 88/3800 82/3000 100/3800 100/3400 105/3600 92/3000 110/3400
Mini Fuel Consumption g/kW.h 206 206
Maximum Torque/Speed N.m/r/min 300/1800 320/1800 330/1800 350/1800 360/1800 350/1800 360/1800
Overall Dimension mm Length:585 Wide:616 High:760
Weight kg 230 235
Injection
Bosch high-pressure electronic-controlled
