The H series marine engine was jointly designed and developed by SDEC and UK Ricardo combining Chinese market demands and internationally proven technologies of advanced Ricardo engines. It is a world first-class power platform manufactured by adopting the GPDP development process and SAIC MOTOR manufacturing standards.
This series marine engine features a compact structure, strong power, low vibration noise, etc., whose technical indexes are all in the leading position in China. It is applied to small inland transportation boat, coastal fishing boat, high speed boat, passenger ship and other ships, as well as 50-150KW marine generator sets.
Outline dimensional drawing
SC4H95/SC4H115
L: 976mm W: 729mm H: 1028mm
SC4H160/SC4H180
L: 976mm W: 729mm H: 1055mm
Technical parameters
Model
Aspiration method
Continuous power/speed kW/r/min
Overload power/speed kW/r/min
Unlimited Navigation Areas Rated power/speed kW/r/min
Unlimited Navigation Areas Overload power/speed kW/r/min
Min.fuel consumption g/kW.h
Oil consumption g/kW.h
Weight kg
Notes
SC4H100CA
T
66/1500
72/1545
63/1500
69/1545
205
≤0.35
495
Main engine
SC4H110CA
T
73/1800
80/1854
70/1800
77/1854
205
≤0.35
495
Main engine
SC4H125CA2
TA
82/1500
91/1545
80/1500
88/1545
192
≤0.35
540
Main engine
SC4H140CA2
TA
93/1500
102/1545
90/1500
99/1545
192
≤0.35
540
Main engine
SC4H155CA2
TA
103/1500
113/1545
100/1500
110/1545
192
≤0.35
540
Main engine
SC4H170CA2
TA
113/1800
125/1854
110/1800
121/1854
192
≤0.35
540
Main engine
SC7H175CA2
TA
115/1500
127/1545
112/1500
123/1545
192
≤0.35
675
Main engine
SC7H195CA2
TA
129/1500
142/1545
125/1500
138/1545
192
≤0.35
675
Main engine
SC7H190CA2
TA
125/1800
137/1854
121/1800
133/1854
192
≤0.35
675
Main engine
SC7H220CA2
TA
144/1800
159/1854
140/1800
154/1854
192
≤0.35
675
Main engine
SC7H235CA2
TA
155/2100
170/2163
150/2100
166/2163
192
≤0.35
675
Main engine
SC7H250CA2
TA
167/2300
184/2369
162/2300
178/2369
192
≤0.35
675
Main engine
SC4H95CF2
T
62/1500
68/1500
60/1500
66/1500
205
≤0.35
495
Auxiliary engine
SC4H115CF2
T
78/1500
86/1500
75/1500
83/1500
205
≤0.35
495
Auxiliary engine
SC4H160CF2
TA
105/1500
116/1500
102/1500
112/1500
192
≤0.35
540
Auxiliary engine
SC4H180CF2
TA
120/1500
132/1500
116/1500
128/1500
192
≤0.35
540
Auxiliary engine
SC7H230CF2
TA
154/1500
170/1500
149/1500
164/1500
192
≤0.35
675
Auxiliary engine
SC7H250CF2
TA
168/1500
185/1500
163/1500
179/1500
192
≤0.35
675
Auxiliary engine
Bore × stroke (mm)
Displacement (L)
Type
Aspiration
Steady speed governing rate (%)
Idling (r/min)
Exhaust temperature (℃)
Compression ratio
Oil capacity (L)
SC4H SC7H 105×124
4.3 6.5
In-line, 4-valve In-line, 6-valve
T-Turbocharged TA-Turbocharged and intercooler
0%-5%
650
≤550
17.3:1/16:1 16:01:00
13.4 20.5
Note
The flywheel house and flywheel are optional of SAE1# and SAE14# or SAE1# and SAE14#.
There are single-layer and dual-layer high pressure oil pipes optional.
Features
With four-valve structure, centrally and vertically arranged fuel injector and new fuel mixing technology, this engine delivers high air intake efficiency, uniform atomization and good load transient response. Its working efficiency is improved by 12%.
The maximum torque is over l000N.m, and the torque reserve is as high as 36%, which is 20% higher than similar products.
The power and economy are both considered under common working conditions, and the minimum fuel consumption is 195g/kW.h.
A 180 BAR high combustion pressure design makes its environmental adaptability 7% higher than the similar products. Without auxiliary air intake heating device, the cold starting temperature is -15℃.
Frame type high strength alloy engine body, one-piece cylinder head and rear gear chamber result in small volume, light weight, high reliability and a noise of 3dB (A) lower than similar products.
By reference to SPS manufacturing standard of German Volkswagen, the average overhaul period is over 15000h, which is 50% longer than similar products.
